Product Name:Prepainted aluminium coil

Types:PE or FVDF coated

Alloy	Specification		Temper	Standard
	Thickness(mm)	Width(mm)		ASTM B209/ EN485
1050,1060,1070,1100,1200	0.03~2.0	15~1570	O, H12, H14, H16, H18, H24, H26, H32, etc.
3003,3004,3005,3105	0.03~2.0	15~1570	O, H12, H14, H16, H18, H24, H26, H32, etc.
5052,5005,5083,5754	0.03~2.0	15~1570	O, H12, H14, H16, H18, H24, H26, H32, etc.
The type of prepainting: PVDF, PE, ACRYLIC The layer of painting: PVDF: >25micron; PE: >18micron Color: RAL or refer to customer's counter sample Coating hardness: (pencil hardness) >2H Impact resistance: no cracking and peeling(50kg/cm, ASTMD-2794:1993) Flexibility(T-bend): <2T MEK resistance: >100 Painted surface can be covered PVC as per customer's request. Gloss: meet customers' request. ID: 150, 405, 508mm, eye to side OR eye to sky with wooden skid. Coil weight: 1.5~2tons per coil. Application: Roofing, Decoration panel, etc.

If you need to know more details, please send us an email to: sales@gostarcn.com
